Raytracing in one weekend - MT-Patched

Introduction

Multithreaded patched version of rt-in-one-weekend-rs.

Setup and Requirements

• Rust version 1.71.1 [2021 edition]

Explanation

1. Select shared resources to do tasks in parallel.

• I used Atomic-Reference-counter to release resources with atomic operation.
• Also I used Mutex to update critical section safely.

• let image_shared_pointer = Arc::new(Mutex::new(image_process::PpmFormat::new(image_width,image_height,255)));
  let progress_shared_pointer = Arc::new(Mutex::new(indicate_bar::IndicateBar::new(image_height as u32)));

2. Write a single threaded version to debug with differential test.

• Differential test is easy. Just compare output between codes which should emit same results.
• To do differential test, We always retain single threaded version of parallel codes.

• if !is_multi_thread
  {
      let mut rand_seed = ChaCha8Rng::seed_from_u64(45);
      let mut world = random_scene(&mut rand_seed);
      let progress_bar = Arc::clone(&progress_shared_pointer);
      for  j in (0..image_height).rev(){
          for i in 0..image_width{
              let mut pixel_color = Vec3::new(0.0, 0.0, 0.0);
              for _ in 0..samples_per_pixel
              {
                  let u = (i as f64 + utility::random_double()) / (image_width-1) as f64;
                  let v = (j as f64 + utility::random_double()) / (image_height-1) as f64;
                  let r = cam.get_ray(u, v);
                  pixel_color += ray_color(r, &mut world, max_depth);

              }
              let mut target_image = image_shared_pointer.lock().unwrap();
              target_image.write_color(color::fcolor_to_icolor(pixel_color, samples_per_pixel),i as usize,j as usize);
          }
          let mut progress_indicator = progress_bar.lock().unwrap();
          progress_indicator.progress_one();
      }
  }

3. Seperate atomic tasks in parallel.

• I simply separated draw part with column in parallel.

•    let thread_count = 12;
      let draw_part_per_thread = image_height / thread_count;
      let residue_count = image_height % thread_count;
      //Draw Residue By Single Thread
      {
          let result_vector = Arc::clone(&image_shared_pointer);
          let mut rand_seed = ChaCha8Rng::seed_from_u64(45);
          //World
          let mut world = random_scene(&mut rand_seed);
          let mut color_vector_per_thread:Vec<Vec<color::Color>> = Vec::new();
          let progress_bar = Arc::clone(&progress_shared_pointer);
          for  j in 0.. residue_count
          {
              let mut column_vec:Vec<Color> = Vec::new();
              for i in 0..image_width{
                  let mut pixel_color = Vec3::new(0.0, 0.0, 0.0);
                  for _ in 0..samples_per_pixel
                  {
                    let u = (i as f64 + utility::random_double()) / (image_width-1) as f64;
                     let v = (j as f64 + utility::random_double()) / (image_height-1) as f64;
                     let r = cam.get_ray(u, v);
                    pixel_color += ray_color(r, &mut world, max_depth);

                  }
                  column_vec.push(color::fcolor_to_icolor(pixel_color, samples_per_pixel));
              }
              color_vector_per_thread.push(column_vec);
              let mut progress_indicator = progress_bar.lock().unwrap();
              progress_indicator.progress_one();
          }
          let mut target_image = result_vector.lock().unwrap();
          target_image.write_color_rows(color_vector_per_thread, 0 , residue_count as usize);

Acknowledge

• rt-in-one-weekend in rust
